Công tắc tiệm cận
Còn hàng
Giá 1.000₫
Đường kính sensor 18mm Khoảng cách phát hiện 8mm Standard sensing target 25×25×1mm (Iron) Nguồn cấp 12-24VDC Leakage current Max. 0.6mA Tần số đáp ứng 350Hz Residual voltage Max. 3.5V Affection by Temp. Max. ±10% for sensing distance at ambient temperature 20℃ Control output 2 to 100mA Insulation resistance Min. 50MΩ Dielectric strength 1,500VAC 50/60Hz for 1minute Vibration 1mm amplitude at frequency of 10 to 55Hz (for 1 min) in each of X, Y, Z directions for 2 hours Shock 500m/s² (approx. 50G) in X, Y, Z direction for 3 times Indicator Operation indicator: Red LED Environment -25 to 70℃, storage: -30 to 80℃ 35 to 95% RH, storage: 35 to 95% RH Protection circuit Surge protection circuit, Overcurrent protection circuit Protection structure IP67 Cable Ø5mm, 2-wire, 2m Material Case/Nut: Nickel plated Brass, Washer: Nickel plated Iron, Sensing surface: PBT, Standard cable (Black): Polyvinyl chloride (PVC), Oil resistant cable (Gray): Oil resistant Polyvinyl chloride (PVC) Weight Approx.122g (approx. 110g) Mã hiệu: PRT18-8DO Nhà sản xuất: Autonics Xuất xứ: Korea
