Đồng hồ đo áp suất 131.11.50

Còn hàng

Giá 10.000₫

Đồng hồ đo áp suất 131.11.50 Dãi đo: 0-20 bar Đường kính: 50mm Môi chất: Khí Hydro Chân đứng Đầu nối 1/4 NPT Accuracy class +/- 3/2/3% of span per ASME B40.100 Grade B Working pressure Steady: 3/4 of full scale value Fluctuating: 2/3 of full scale value Short time: full scale value Operating temperature Ambient: -40°F to +140°F (-40°C to +60°C) Medium: +212°F (+100°C) maximum Movement Stainless steel Dial White aluminum with black lettering, with stop pin Pointer Black aluminum Case Stainless steel Window Snap-in polycarbonate Model: 131.11.50 NSX: Wika/Poland

Đồng hồ đo áp suất 131.11.50

Dãi đo: 0-20 bar
Đường kính: 50mm
Môi chất: Khí Hydro
Chân đứng
Đầu nối 1/4 NPT
Accuracy class +/- 3/2/3% of span per ASME B40.100 Grade B
Working pressure
Steady: 3/4 of full scale value
Fluctuating: 2/3 of full scale value
Short time: full scale value
Operating temperature
Ambient: -40°F to +140°F (-40°C to +60°C)
Medium: +212°F (+100°C) maximum
Movement Stainless steel
Dial White aluminum with black lettering, with stop pin
Pointer Black aluminum
Case Stainless steel
Window Snap-in polycarbonate
Model: 131.11.50
NSX: Wika/Poland
