Công tắc áp suất dầu JM26 1M1 2B07000xxxx1

Công tắc áp suất dầu JM26 1M1 2B07000xxxx1

Chủng loại: Pressure gauge with electric contact JM2 (micro switch type)
Đường kính mặt Φ150
Kiểu lắp đặt: panel
Type: stem: B type (mounting hole) One contact; panel: D type (mounting clamp) One contact
Connection: 1/2 NPT
Wetted parts: general use (available up to 35Mpa range)
Pressure range (Mpa): -0.1 to 2
Contact: L: lower limit with one contact
Switch: standard
Electrical wire outlet: gland JIS 20b
Window: Inorganic glass (standard)
Treatment: not required
Other additional spec.: not required
Document: required
Electrical Rating:
Resistance Load                   Inductive Load
AC   125V    15A                   AC     125V     15A
AC    250V   15A                   AC     250V     15A
DC      30V     2A                   DC      30V       1A
DC     125V    0.5A                DC    125V       0.05A
