Cảm biến vị trí VOS2T-12R0
Còn hàng
Giá 1.000₫
Kiểu tác động: Direct or reverse
- Wiring conduit: G 1/2
- Connection: M3.5 screw terminals (torque 0.8 N·m)
- Materials: Housing/ Screw/ Cable connector/ Level: Cast aluminium/ Nickel-plated steel/ Nypon 66/ Stainless-steel (applicable cable's external dia. 6.5 – 8.5 mm)
- Isolation: Output to metal housing
- Zero adjustment: -2.2 – +2.2° of input angle
- Span adjustment: 22.5 – 45° of input angle (4-20 mA)
- Input: Mechanical rotating angle
- Effective rotating angle: Approx. -27 – +27° (54°)
- Linearity assured range: -22.5 – +22.5° (45°)
- Stopper strength: 1.37 N·m (1.011 ft·lbf)
- Stroke 10 – 30 mm (0.39" – 1.18")
- Return spring: Clockwise return
- Protection: IP66
Model: VOS2T-12R0 SER NO : 3E006440
Hãng sản xuất: M-System
Xuất xứ: Japan
