Cảm biến đo độ rung 330525-00 XA 330525

Liên hệ

Giá 10.000₫

Cảm biến đo độ rung 330525-00 XA 330525 330525 Velomitor* XA Piezo-velocity Sensor Sensitivity: 3.94mV/mm/s(100mV/in/s)±5% Temp. Sensitivity: -14% ~ 7.5% typical over the operating temp. range. Velocity Range: 1270 mm/s (50 in/s) peak Transverse sensitivity: Less than 5% of sensitivity Amplitude Linearity: ±2% to 152 mm/s (6in/s) peak. Power Requirements DC Voltage: -22 to -30VDC Weight 156g(5.5oz), typical Diameter 28mm(1.1in) Height 73.1mm (2.88in) Case Material 316L stainlesssteel Connector 2-pin Mil-C-26482 hermetically-sealed, 316Lstainlesssteelshell. Model 330525-00 XA 330525 Nhãn hiệu: Bently Nevada Xuất xứ: USA

Cảm biến đo độ rung 330525-00 XA 330525

330525 Velomitor* XA Piezo-velocity Sensor
Sensitivity: 3.94mV/mm/s(100mV/in/s)±5%
Temp. Sensitivity: -14% ~ 7.5% typical over the operating temp. range.
Velocity Range: 1270 mm/s (50 in/s) peak
Transverse sensitivity: Less than 5% of sensitivity
Amplitude Linearity: ±2% to 152 mm/s (6in/s) peak.
Power Requirements DC Voltage: -22 to -30VDC
Weight 156g(5.5oz), typical
Diameter 28mm(1.1in)
Height 73.1mm (2.88in)
Case Material 316L stainlesssteel
Connector 2-pin Mil-C-26482 hermetically-sealed, 316Lstainlesssteelshell.

Model 330525-00 XA 330525

Nhãn hiệu: Bently Nevada

Xuất xứ: USA
