Cảm biến đo độ rung 330103-00-04-10-01-00

Liên hệ

Giá 10.000₫

Cảm biến đo độ rung 330103-00-04-10-01-00 - 3300 XL 8 mm Probe - M10 x 1 thread, without armor - Unthreaded Length Option: 0 mm - Overall Case Length Option: 40mm - Total Length Option: 1.0 metre (3.3 feet) - Connector and Cable-Type Option: Miniature coaxial ClickLocTM connector with connector protector, standard cable - Extension cable capacitance: 69.9 pF/m (21.3 pF/ft) typical - Linear Range: 2 mm (80 mils). Linear range begins at approximately 0.25 mm (10 mils) from target and is from 0.25 to 2.3 mm (10 to 90 mils) (approximately –1 to –17 Vdc). Part number: 330103-00-04-10-01-00 Nhãn hiệu: Bently Nevada Xuất xứ: USA

Cảm biến đo độ rung 330103-00-04-10-01-00

- 3300 XL 8 mm Probe - M10 x 1 thread, without armor
- Unthreaded Length Option: 0 mm
- Overall Case Length Option: 40mm
- Total Length Option: 1.0 metre (3.3 feet)
- Connector and Cable-Type Option: Miniature coaxial ClickLocTM connector with connector protector, standard cable
- Extension cable capacitance: 69.9 pF/m (21.3 pF/ft) typical
- Linear Range: 2 mm (80 mils). Linear range begins at approximately 0.25 mm (10 mils) from target and is from 0.25 to 2.3 mm (10 to 90 mils) (approximately –1 to –17 Vdc).
Part number: 330103-00-04-10-01-00

Nhãn hiệu: Bently Nevada

Xuất xứ: USA
