Cảm biến đo vị trí vòi thổi bụi Z4V10H 336-11Z-1593-6
Liên hệ
Giá Liên hệ
EN ISO 13849-1
Materials
- Material of the housings: Plastic, glass-fibre reinforced thermoplastic, self-extinguishing
- Lever material: Metal film
- Material of the rod: Plastic
- Material of the contacts: Silver
Mechanical life: 30.000.000 operations
Switching frequency: max. 5000 /h
Design of actuating element: Rod lever
Actuating torque: min. 26 Ncm
Protection class IP67
Rated impulse withstand voltage Uimp 6 kV
Rated insulation voltage Ui 500 V
Utilisation category AC-15: 230 V / 4 A,
DC-13: 24 V / 4 A
1 Normally open contact (NO) / 1 Opener (NC)
Mã hiệu: SZ4V10H 336-11Z-1593-6
Nhà sản xuất: Clyde Bergemann
Xuất xứ: China
EN ISO 13849-1
Materials
- Material of the housings: Plastic, glass-fibre reinforced thermoplastic, self-extinguishing
- Lever material: Metal film
- Material of the rod: Plastic
- Material of the contacts: Silver
Mechanical life: 30.000.000 operations
Switching frequency: max. 5000 /h
Design of actuating element: Rod lever
Actuating torque: min. 26 Ncm
Protection class IP67
Rated impulse withstand voltage Uimp 6 kV
Rated insulation voltage Ui 500 V
Utilisation category AC-15: 230 V / 4 A,
DC-13: 24 V / 4 A
1 Normally open contact (NO) / 1 Opener (NC)
Mã hiệu: SZ4V10H 336-11Z-1593-6
Nhà sản xuất: Clyde Bergemann
Xuất xứ: China
