Cảm biến đo vị trí vòi thổi bụi Z4V10H 336-11Z-1593-6

Liên hệ

Giá Liên hệ

EN ISO 13849-1 Materials - Material of the housings: Plastic, glass-fibre reinforced thermoplastic, self-extinguishing - Lever material: Metal film - Material of the rod: Plastic - Material of the contacts: Silver Mechanical life: 30.000.000 operations Switching frequency: max. 5000 /h Design of actuating element: Rod lever Actuating torque: min. 26 Ncm Protection class IP67 Rated impulse withstand voltage Uimp 6 kV Rated insulation voltage Ui 500 V Utilisation category AC-15: 230 V / 4 A, DC-13: 24 V / 4 A 1 Normally open contact (NO) / 1 Opener (NC)     Mã hiệu:  SZ4V10H 336-11Z-1593-6  Nhà sản xuất: Clyde Bergemann Xuất xứ: China

EN ISO 13849-1
Materials
- Material of the housings: Plastic, glass-fibre reinforced thermoplastic, self-extinguishing
- Lever material: Metal film
- Material of the rod: Plastic
- Material of the contacts: Silver
Mechanical life: 30.000.000 operations
Switching frequency: max. 5000 /h
Design of actuating element: Rod lever
Actuating torque: min. 26 Ncm
Protection class IP67
Rated impulse withstand voltage Uimp 6 kV
Rated insulation voltage Ui 500 V
Utilisation category AC-15: 230 V / 4 A,
DC-13: 24 V / 4 A
1 Normally open contact (NO) / 1 Opener (NC)

 Mã hiệu:  SZ4V10H 336-11Z-1593-6

 Nhà sản xuất: Clyde Bergemann

Xuất xứ: China
