Công tắc nhiệt độ

Mã hiệu: Part Code No.74130768 for Silica Analyzer 7180

- Thermistor of Silica analyzer 7180
- Temperature range -5 to 120°C
- Temperature element Thermistor (Sensor-contained)
- Thông số bộ phân tích Silica 7180:
+ Measuring range: 0.000 to 0.500/0.00 to 5.00 mg/l (SiO2 contrentration)
+ Repeatability: ± 2% Full Scale or ± 0.002 mg/l (Use larger value)
+ Measuring method: Molybdenum blue absorptiormetry
+ Measuring Cycle time: 5/ 10/ 15/30 & 60 minutes (Select one)
+ Concentration display: Digital Display (Effective range: 3-Digit number)(Display by the 0.001 mg/l for less than 1 mg/l; Display by the 0.01 mg/l for more than 1 mg/l)
+ Sample water condition: Flow rate/ 200 to 1000 ml/min; Pressure/ 0.1 to 0.7 Mpa; Temp/ 5 to 45 DegC; Phosphate concentration/ less than 30 mg/l(ppm); pH/ more than 7
+ Measuring points: 1 point or 2 to 6 point (when using sample selector)
+ Reagent consumption: Reagent #1; #2; #3: 0.5l/week (approx 2l/ month)
+ Power: AC100V±10%/ 50 or 60Hz; Max 700W
+ Air source: instrument air 0.4 to 0.6 Mpa
+ Output signal: DC 4 to 20 mA/ High range/ High concentration alarm/ Sample stop/ Abnormal condition analyzerr
+ Overall size: WxHxD (450mmx840mmx365mm)
NSX: Nikkiso/Japan
