Bộ Thermistor No.74130768

Liên hệ

Giá Liên hệ

Công tắc nhiệt độ Mã hiệu: Part Code No.74130768 for Silica Analyzer 7180  - Thermistor of Silica analyzer 7180 - Temperature range -5 to 120°C - Temperature element Thermistor (Sensor-contained) - Thông số bộ phân tích Silica 7180:    + Measuring range: 0.000 to 0.500/0.00 to 5.00 mg/l (SiO2 contrentration)    + Repeatability: ± 2% Full Scale or ± 0.002 mg/l (Use larger value)    + Measuring method: Molybdenum blue absorptiormetry    + Measuring Cycle time: 5/ 10/ 15/30 & 60 minutes (Select one)    + Concentration display: Digital Display (Effective range: 3-Digit number)(Display by the 0.001 mg/l for less than 1 mg/l; Display by the 0.01 mg/l for more...

Công tắc nhiệt độ

Mã hiệu: Part Code No.74130768 for Silica Analyzer 7180

- Thermistor of Silica analyzer 7180
- Temperature range -5 to 120°C
- Temperature element Thermistor (Sensor-contained)
- Thông số bộ phân tích Silica 7180:
   + Measuring range: 0.000 to 0.500/0.00 to 5.00 mg/l (SiO2 contrentration)
   + Repeatability: ± 2% Full Scale or ± 0.002 mg/l (Use larger value)
   + Measuring method: Molybdenum blue absorptiormetry
   + Measuring Cycle time: 5/ 10/ 15/30 & 60 minutes (Select one)
   + Concentration display: Digital Display (Effective range: 3-Digit number)(Display by the 0.001 mg/l for less than 1 mg/l; Display by the 0.01 mg/l for more than 1 mg/l)
   + Sample water condition: Flow rate/ 200 to 1000 ml/min; Pressure/ 0.1 to 0.7 Mpa; Temp/ 5 to 45 DegC; Phosphate concentration/ less than 30 mg/l(ppm); pH/ more than 7
   + Measuring points: 1 point or 2 to 6 point (when using sample selector)
   + Reagent consumption: Reagent #1; #2; #3: 0.5l/week (approx 2l/ month)
   + Power: AC100V±10%/ 50 or 60Hz; Max 700W
   + Air source: instrument air 0.4 to 0.6 Mpa
   + Output signal: DC 4 to 20 mA/ High range/ High concentration alarm/ Sample stop/ Abnormal condition analyzerr
   + Overall size: WxHxD (450mmx840mmx365mm)
NSX: Nikkiso/Japan
