Bộ điều chỉnh lưu lượng Code No 22410268

Còn hàng

Giá 1.000₫

Bộ điều chỉnh lưu lượng Code No 22410268 - Type: Flow meter - Fluid: Water - Flow rate: 50 to 500 ml/min - Max Press: 0.1 Mpa - Nor Press: 0.02 Mpa - Max Temp: 60 DegC - Nor Temp: 35 DegC - Graduation: 50 ml/min - Case: Chrome Plating - Connection: + Size/ Phi 6; Conn/ Half Union - Material: Nipple/ SUS304; Nut/ C3604B; Casing/ C2700T; Float/ SUS304; Tapered tube/ Glass; Bracket/ C2801P; Sopper/ SUS316; Packing/ Neoprene; Ring/ Polypropylene; Nut/ Polypropylene - Overall length: 250mm;  - Two holes for mounting: phi 4 - Tube size: Phi 6 Model: Code No 22410268 NSX: Nikkiso/Japan

Bộ điều chỉnh lưu lượng Code No 22410268

- Type: Flow meter
- Fluid: Water
- Flow rate: 50 to 500 ml/min
- Max Press: 0.1 Mpa
- Nor Press: 0.02 Mpa
- Max Temp: 60 DegC
- Nor Temp: 35 DegC
- Graduation: 50 ml/min
- Case: Chrome Plating
- Connection: + Size/ Phi 6; Conn/ Half Union
- Material: Nipple/ SUS304; Nut/ C3604B; Casing/ C2700T; Float/ SUS304; Tapered tube/ Glass; Bracket/ C2801P; Sopper/ SUS316; Packing/ Neoprene; Ring/ Polypropylene; Nut/ Polypropylene
- Overall length: 250mm;
- Two holes for mounting: phi 4
- Tube size: Phi 6
Model: Code No 22410268
NSX: Nikkiso/Japan
