Bộ điều chỉnh áp mẫu nước tự động 2045P

Bộ điều chỉnh áp mẫu nước tự động 2045P

- Type: Auto Conflow
- Flow rate:  Max 20l/ min
- Primary-side presssure: 0.3 to 32.4 Mpa
- Secondary-side pressure: 0.3 Mpa (Standard pressure)
- Fluid tenperature: 10-70 DegC
- Fluid rate stability: Within preset value  ±10%
- Secondary-side pressure setting accuracy: Within ±0.012MPa
- Required time for full stroke  (0 -100%): Approx.I.25min/50Hz or Approx. 1 luin/60Hz
- Connecting pipeline size: 9.530 OD
- Output signaling(Max.contact rating)
           Contact Signals: AC120V/IA/SPST
                      + Automatic mode: OFF during automatic operation
                      + Conflow abnormal:
                      + Inlet valve open: Contact signal OFF with a command of "Inlet Valve Open"
- Input signaling (Max contact rating:
          Contact signals: AC50VA
                       + Core rod insertion command: Conre rod insertion at ON
                       + Inlet Valve Open command: Inlet valve Open at OFF
                       + A-Type: Inlet valve working check; B-type: Inlet valve not working check
- Digital display: + Secondary-side pressure: 0.0-0.99MPa
                              + Stroke display: 0-100%
- Protecting structure Drip-proof constmction
- Power requirement: 100/110 VAC; 50/60Hz
- Embient temperature: 0 50°C
- Relative humidity Less than 90%RH
- Insulation resistance: ore than 5M Q with a 500V Megger
-  Overall dimension: H-type: 280mm (W) X700mm(H) X685 mm (D)
                         V-type: 280mm (W) X910mm(H) X480 mm (D)
 Controller-separated VS-type: 280mm (W) X730mm (H) X420mm (D)
Model: 2045P
NSX: Nikkiso/Japan
