Bộ chuyển đổi độ rung

- Kiểu: 3300 XL Proximitor Sensor
- Áp dụng cho: 3300XL 5/8mm probe and extension cable
- Power: Requires -17.5 Vdc to -26 Vdc without barriers at 12 mA maximum consumption
- Supply Sensitivity: Less than 2 mV change in output voltage per volt change in input voltage
- Output resistance: 50 Ω
- Linear Range: 2 mm (80 mils)
- Recommended Gap Setting for Radial Vibration: -9Vdc [approximately 1.27 mm (50 mils)]
- Incremental Scale Factor (ISF): 7.87 V/mm (200 mV/mil) ± 6.5%
- Deviation from best fit straight line (DSL): Less than ±0.038 mm (±1.5 mil) with components at 0 °C to +45°C
- Total Length: 5.0 metre (16.4 feet) system length, DIN mount
- Agency Approval Option: No required

Model: 330180-51-00 S/N: 12C01PC4 W/O: 1998

Nhà sản xuất: Bently Nevada

Xuất xứ: USA
